GP Series
GP25-12
Multi-Purpose Robot with extended reach of 2m and 12kg payload
Обзор
The GP25-12 is a highly versatile 6-axis industrial robot with extended reach of 2.010 mm, 12 kg payload, and an outstanding repeatability of +/- 0.02 mm.
The GP25-12 robot is offering a perfectly tuned payload / speed / wrist allowable moment combination, for impressive speed and acceleration performance. The small footprint, slim arm design allows for minimum installation space and minimizes interference with peripheral devices. Installation is quick and efficient - media cables are guided through the hollow arm and wrist structure.
This robot is also available with high IP65/67 dust & liquid protection to operate in harsh environments.
The GP25-12 is perfect for a wide range of applications, perfect for machine tending, material handling, material removal, assembly, additive manufacturing or dispensing.
Технические детали
- Количество осей
- 6
- Полезная нагрузка
- 12 kg
- Максимальный Рабочий Диапазон
- 2010 mm
- Повторяемость
- 0.03 mm
- Вес
- 260 kg
- Источник питания
- 2 kVA
- Maximum Speed S Axis
- 210 °/s
- Maximum Speed L Axis
- 210 °/s
- Maximum Speed U Axis
- 220 °/s
- Maximum Speed R Axis
- 435 °/s
- Maximum Speed B Axis
- 435 °/s
- Maximum Speed T Axis
- 700 °/s
- Варианты монтажа
- Ceiling, Wall, Floor
- Дальнейшие уточнения
- x Нет
